Englander
0
Englander
EnglanderSKU: ESW0020

25-CBPAH

Out of stock

Free Curbside Delivery.See Shipping & Delivery Policy

This stove is all business - powerful enough to heat up to 2,200 ft², keeping your home warm all season long.

Full description
24 1/2"L X 25 1/2"P X 35 1/2"H
500 - 2,200 ft²
75 h
120 lb
Full specifications
Alain
ALAIN'S ADVICE
Description

This stove is all business - powerful enough to heat up to 2,200 ft², keeping your home warm all season long. And, though less bulky than similar designs, the huge hopper on this stove can hold 120 lbs. of pellets (three bags), allowing it to burn up to 75 hours between reloading.

It is powered by our one-touch, auto-start igniter and our proven, user-friendly control board for quick and easy operation – just press ON and choose your desired heat setting. The viewing glass with air wash gives a great view of the fire, and a fresh air hook-up kit is included. The stove is also Mobile Home approved.

• Made in USA

• Heats up to 2,200 ft²

• Hopper holds 120 lb of wood pellets

• Up to 75h burn time per filling

• EPA latest certification means High Efficiency and Low Emissions

• Mobile Home Approved

• Outside Air Kit Included

Specifications

General features

Mobile home approved
Yes, with fresh air intake
Certified according to applicable standards
By an accredited laboratory (CAN/USA)
Premium quality blower included (CFM)
176 CFM included
Combustion technology
Top-feed
Baffle type
Mild steel
Flue outlet diameter
3"
Recommended chimney diameter
3"-4"
Type of chimney
ULC/ORD-C441, CAN/ULC S609, UL 641 (TYPE L)
Overall dimension (Width)
24 1/2"
Overall dimension (Height)
35 1/2"
Overall dimension (Depth)
25 1/2"
Voltage and frequency
120 VAC / 60 Hz
Door type
Single, glass with cast iron frame
Glass type
Ceramic glass
Glass surface - W x H
8" x 8"
High-efficiency certified appliance
Yes, EPA 2020 approved
Canadian Standard (emissions)
CSA B415.1-10
USA Standard (emissions)
EPA, ASTM E2779
Canadian Standard (safety)
ULC S627
USA Standard (safety)
UL 1482, ASTM E1509
Warranty
5 year Limited
Shipping weight
300 lb

Appliance performance

Fuel type(12)
Pellet (Premium grade or better)
Recommended heating area(10)
500 - 2,200 ft²
Hopper capacity
120 lb
Maximum burn time(10)
75 h
Maximum heat input rate (4)
31,885 BTU/h (9.35 kW)
Minimum overall heat output rate(5)
11,692 BTU/h (3.43 kW)
Maximum overall heat output rate(5)
22,988 BTU/h (6.74 kW)
Minimum average overall efficiency (HHV)(6)(8)
68.40%
Maximum average overall efficiency (LHV)(6)(7)
73.70%
Optimum efficiency(2)
87.40%
Optimum heat transfer efficiency(9)
74%
Burn rate
1.6 - 3.75 lb/h
Average particulate emission rate(3)
0.763 g/h
Average CO(11)
0.78 g/h
Average electrical power consumption for ignition cycle (1)
5.65A (661 W)
Average electrical power consumption for continuous operation (1)
4.15A (361 W)

Clearances

Canada
United States
Clearance - Back wall 0"0"Clearance - Side wall 8"8"Clearance - Corner 6"6"Clearance - Base of the unit to ceiling**84"84"
Manuals and Instructions

Consult the available manuals and leaflets for more information on performance, installation and use requirements, etc.
