Ventis
VentisSKU: VB00025
HEP55
Out of stock
Curbside Delivery.See Shipping & Delivery Policy
Recommended for installation
These options allow you to get the most out of your appliance.
Out of stock
AC01393HOPPER EXTENSION
Out of stock
AC02586ASH VACUUM CLEANER
Out of stock
AC05558DIGITAL WALL THERMOSTAT
Out of stock
Out of stock
Out of stock
Out of stock
Out of stock
Out of stock
Out of stock
Out of stock
Out of stock
Out of stock
Out of stock
Accessories
Description
▪ Top-feed pellet stove
▪ Up to 69 hours burn time
▪ Hopper capacity of 80 lb
▪ Glass airwash system for a cleaner view of the flames
▪ EPA Certified
▪ Intuitive electronic control
▪ Certified for mobile home and alcove installation
▪ Proudly made in Canada
Specifications
General features
Alcove installation approved
Yes
Mobile home approved
Yes, with fresh air intake
Certified according to applicable standards
CAN/USA accredited laboratory
Premium quality blower included (CFM)
176 CFM included
Combustion technology
Top-feed
Baffle type
Stainless steel
Flue outlet diameter
3"
Recommended chimney diameter
3" | 4"
Type of chimney
ULC/ORD-C441, CAN/ULC S609, UL 641 (TYPE L)
Overall dimension (Width)
25 1/8"
Overall dimension (Height)
36 1/8"
Overall dimension (Depth)
29 1/2"
Voltage and frequency
120 VAC / 60 Hz
Noise level at 6 feet
47 dBa (+/- 3 dBa) - 60 dBa (+/- 3 dBa)
Door type
Single, glass with cast iron frame
Glass type
Ceramic glass
Glass surface - W x H
16 1/4" x 7 3/4"
Canadian Standard (emissions)
CSA B415.1-10
USA Standard (emissions)
EPA
Canadian Standard (safety)
ULC S627
USA Standard (safety)
UL 1482, ASTM E1509
Warranty
Limited lifetime
Shipping weight
277lb (126 kg)
Appliance performance
Fuel type(12)
Pellet (Premium grade or better)
Heating area(10)
500 - 2,000 ft²
Hopper capacity
80 lb (36 kg)
Maximum burn time(10)
69 h
Maximum heat input rate
(4)
39,260 BTU/h (11.5 kW)
Minimum overall heat output rate(5)
6,648 BTU/h (1.95 kW)
Maximum overall heat output rate(5)
28,540 BTU/h (8.36 kW)
Minimum average overall efficiency (HHV)(6)(8)
70.3 %
Maximum average overall efficiency (LHV)(6)(7)
75.8 %
Optimum efficiency(2)
78.4 %
Optimum heat transfer efficiency(9)
73 %
Burn rate
1.2 - 4.7 lb/h
Average particulate emission rate(3)
0.96 g/h
Average CO(11)
7.6 g/h
Average electrical power consumption for ignition cycle
(1)
3.02A (360 W)
Average electrical power consumption for continuous operation
(1)
1.3 - 2.5A (51 - 140 W)
Clearances
Canada
United States
Manuals and Instructions
Consult the available manuals and leaflets for more information on performance, installation and use requirements, etc.
Frequently Asked Questions
Our stove and fireplace expert Alain answers your questions about this product.
