Drolet

DroletSKU: DB03205

DECO II

Out of stock

Free Curbside Delivery.See Shipping & Delivery Policy

Sleek version of the traditional wood stove, the Deco II can heat up to 1,800 ft² with 65,000 BTU/h of maximum power.

Full description

Dimension23 7/8"L X 23"P X 36 5/8"H

Recommended heating area500 - 1,800 ft²

Maximum log length18"

Average particulate emission rate2.4 g/h

Full specifications

ALAIN'S ADVICE

Recommended for installation

These options allow you to get the most out of your appliance.

AC01299RIGID FIRESCREEN

Out of stock

AC013365"Ø FRESH AIR INTAKE KIT

Out of stock

AC02050BLOWER WITH VARIABLE SPEED CONTROL | 100 CFM

Out of stock

AC02055QUICK CONNECT THERMODISC

Out of stock

AC03513HEAT OPERATED ROTATING FAN (180 CFM)

Out of stock

Subtotal:CAD $0.00

Accessories

Description

Sleek version of the traditional wood stove, the Deco II can heat up to 1,800 ft² with 65,000 BTU/h of maximum power. EPA 2020 certified at 2.4 g/h, this non-catalytic wood stove stands out with its modern design, its higher-than-average height and its storage space under the appliance.

Included: pedestal with ash drawer, top air deflector, ceramic glass, ash lip, air damper

▪ Up to 7 hours burn time
▪ Up to 18" logs
▪ Heavy duty 5/16" steel top reinforced with a stainless steel heat shield
▪ EPA certified
▪ Proudly made in Canada
▪ Limited lifetime warranty
▪ Certified for mobile home and alcove installation

Any installation must be done according to the data and drawings detailed in the owner’s manual.

Specifications

General features

Alcove installation approved

Yes

Mobile home approved

Yes, with fresh air intake

Certified according to applicable standards

By an accredited laboratory (CAN/USA)

Overall dimension (Width)

23 7/8"

Overall dimension (Height)

36 5/8"

Overall dimension (Depth)

23"

Premium quality blower included (CFM)

Optional

Combustion technology

Non-catalytic

Stainless-steel secondary-air system

Yes

Flue outlet diameter

Distance-center of the flue outlet to back unit

7 1/2"

Distance-center of the flue outlet to side unit

12"

Recommended chimney diameter

Type of chimney

CAN/ULC S629, UL 103 HT (2100 °F)

Minimum chimney height

12'

Door type

Single, glass with cast iron frame

Door opening size (Width)

17 1/4"

Door opening size (Height)

Glass type

Ceramic glass

Glass surface - W x H

15 3/4" x 9 3/4"

Steel thickness-body

3/16"

Steel thickness-top

5/16"

Firebox size (Width)

19 5/8"

Firebox size (Height)

11 7/8"

Firebox size (Depth)

13 1/2"

Log positioning

Loading over width

Maximum log length

18"

Firebox lined with refractory bricks

Yes

Baffle type

High quality vermiculite

High-efficiency certified appliance

Yes, EPA 2020 approved

Canadian Standard (emissions)

CSA B415.1-10

USA Standard (emissions)

EPA

Canadian Standard (safety)

ULC S627

USA Standard (safety)

UL 1482, UL 737

Warranty

Limited lifetime

Shipping weight

321 lb (146 kg)

Approved as add-on to an existing furnace

Appliance performance

Fuel type

Dry cordwood (16" recommended)

Recommended heating area(9)

500 - 1,800 ft²

Overall firebox volume

1.86 ft³

EPA loading volume

1.44 ft³

Maximum burn time(9)

7 h

Maximum heat output-dry cordwood(4)

65,000 BTU/h (19 kW)

Minimum overall heat output rate(4)(5)

9,800 BTU/h (2.87 kW)

Maximum overall heat output rate(4)(5)

52,200 BTU/h (15.3 kW)

Average overall efficiency-dry cordwood (HHV)(5)(6)

68 %

Average overall efficiency-dry cordwood (LHV)(5)(7)

73 %

Optimum efficiency(1)(2)

76 %

Optimum heat transfer efficiency(8)

75 %

Average particulate emission rate(3)

2.4 g/h

Average CO(10)

103 g/h

Clearances

Canada

United States

Single wall pipe

Double wall pipe

Single wall pipe

Double wall pipe

Clearance - Back wall14 1/2"14 1/2"14 1/2"14 1/2"Clearance - Side wall16"16"16"16"Clearance - Corner12"12"12"12"Clearance - Base of the unit to ceiling**84"84"84"84"

Manuals and Instructions

Consult the available manuals and leaflets for more information on performance, installation and use requirements, etc.

Wood stove manual | Safety notifications & general information

Appliance dimensions

Installation & Operation Requirements
