Drolet

DroletSKU: DB03220

DECO ALTO

Out of stock

Free Curbside Delivery.See Shipping & Delivery Policy

A streamlined version of the traditional wood stove, the Deco Alto is ideal for spaces up to 2,100 ft².

Full description

Dimension25 5/8"L X 26 1/2"P X 39 3/4"H

Recommended heating area500 - 2,100 ft²

Maximum log length20"

Average particulate emission rate2.3 g/h

Full specifications

ALAIN'S ADVICE

Recommended for installation

These options allow you to get the most out of your appliance.

AC02050BLOWER WITH VARIABLE SPEED CONTROL | 100 CFM

Out of stock

AC02055QUICK CONNECT THERMODISC

Out of stock

AC01315RIGID FIRESCREEN

Out of stock

AC013365"Ø FRESH AIR INTAKE KIT

Out of stock

AC03513HEAT OPERATED ROTATING FAN (180 CFM)

Out of stock

Subtotal:CAD $0.00

Accessories

Description

A streamlined version of the traditional wood stove, the Deco Alto is ideal for spaces up to 2,100 ft². This large non-catalytic model releases up to 75,000 BTU/h and is certified according to the latest environmental standards. Its clean lines, higher than average height and base with integrated storage space set the Deco Alto apart from other appliances on the market.

Included: pedestal with log storage, rear air deflector, ash lip, ash drawer, air damper

Features:
▪ Up to 8 hours burn time
▪ Up to 20" logs
▪ 2.4 ft³ firebox
▪ Cast iron door with adjustable hinges and ceramic glass
▪ Heavy duty 5/16" steel top reinforced with a stainless steel heat shield
▪ EPA certified
▪ Proudly made in Canada
▪ Limited lifetime warranty
▪ Certified for mobile home and alcove installation
▪ This model qualifies for the US tax credit

Any installation must be done according to the data and drawings detailed in the owner’s manual.

Specifications

General features

Alcove installation approved

Yes

Mobile home approved

Yes, with fresh air intake

Certified according to applicable standards

By an accredited laboratory (CAN/USA)

Overall dimension (Width)

25 5/8"

Overall dimension (Height)

39 3/4"

Overall dimension (Depth)

26 1/2"

Premium quality blower included (CFM)

Optional

Combustion technology

Non-catalytic

Stainless-steel secondary-air system

Yes

Flue outlet diameter

Distance-center of the flue outlet to back unit

7 3/8"

Distance-center of the flue outlet to side unit

12 7/8"

Recommended chimney diameter

Type of chimney

CAN/ULC S629, UL 103 HT (2100 °F)

Minimum chimney height

12'

Door type

Single, glass with cast iron frame

Door opening size (Width)

17 1/2"

Door opening size (Height)

Glass type

Ceramic glass

Glass surface - W x H

16 3/4" x 10 1/4"

Steel thickness-body

3/16"

Steel thickness-top

5/16"

Firebox size (Width)

21"

Firebox size (Height)

11 7/8"

Firebox size (Depth)

16 1/2"

Log positioning

Loading over width

Maximum log length

20"

Firebox lined with refractory bricks

Yes

Baffle type

High quality vermiculite

High-efficiency certified appliance

Yes, EPA 2020 approved

Canadian Standard (emissions)

CSA B415.1-10

USA Standard (emissions)

EPA

Canadian Standard (safety)

ULC S627

USA Standard (safety)

UL 1482, UL 737

Warranty

Limited lifetime

Shipping weight

390 lb (177 kg)

Appliance performance

Fuel type

Dry cordwood (16" recommended)

Recommended heating area(9)

500 - 2,100 ft²

Overall firebox volume

2.4 ft³

EPA loading volume

1.95 ft³

Maximum burn time(9)

8 h

Maximum heat output-dry cordwood(4)

75,000 BTU/h (22 kW)

Minimum overall heat output rate(4)(5)

14,200 BTU/h (4.16 kW)

Maximum overall heat output rate(4)(5)

44,500 BTU/h (13.04 kW)

Average overall efficiency-dry cordwood (HHV)(5)(6)

72 %

Average overall efficiency-dry cordwood (LHV)(5)(7)

77 %

Optimum efficiency(1)(2)

79 %

Optimum heat transfer efficiency(8)

76 %

Average particulate emission rate(3)

2.3 g/h

Average CO(10)

69 g/h

Clearances

Canada

United States

Single wall pipe

Double wall pipe

Single wall pipe

Double wall pipe

Clearance - Back wall14 1/2"14 1/2"14 1/2"14 1/2"Clearance - Side wall22"22"22"22"Clearance - Corner12"12"12"12"Clearance - Base of the unit to ceiling**84"84"84"84"

Manuals and Instructions

Consult the available manuals and leaflets for more information on performance, installation and use requirements, etc.

Installation and user's manual

Wood stove manual | Safety notifications & general information

Appliance dimensions
