Drolet

DroletSKU: DB07300

HT-3000

Out of stock

Free Curbside Delivery.See Shipping & Delivery Policy

Ideal for heating spaces up to 2,700 ft², the HT-3000 is a wood stove with an impressive output of 110,000 BTU/h.

Full description

Dimension28 1/8''L X 31 1/4''P X 36 3/8''H

Recommended heating area1,000 - 2,700 ft²

Maximum log length22"

Average particulate emission rate1.6 g/h

Full specifications

ALAIN'S ADVICE

Recommended for installation

These options allow you to get the most out of your appliance.

AC01281RIGID FIRESCREEN

Out of stock

AC013365"Ø FRESH AIR INTAKE KIT

Out of stock

AC02050BLOWER WITH VARIABLE SPEED CONTROL | 100 CFM

Out of stock

AC02055QUICK CONNECT THERMODISC

Out of stock

AC03513HEAT OPERATED ROTATING FAN (180 CFM)

Out of stock

Subtotal:CAD $0.00

Accessories

Description

Ideal for heating spaces up to 2,700 ft², the HT-3000 is a wood stove with an impressive output of 110,000 BTU/h. EPA certified at 1.6 g/h, this non-catalytic appliance represents an eco-responsible heating source. Completely redesigned, the HT-3000 succeeds the HT2000 while retaining its reliability and distinctive look. Its very large combustion chamber allows logs to be loaded across the width and depth.

Included: pedestal with ash drawer, ceramic glass, ash lip, air damper

▪ Up to 10 hours burn time
▪ Up to 22" logs
▪ 3.5 ft³ firebox
▪ Heavy duty 5/16" steel top reinforced with C-Cast heat shield
▪ Insulated top panel for added durability
▪ EPA certified
▪ Proudly made in Canada
▪ Limited lifetime warranty
▪ Certified for mobile home and alcove installation
▪ This model qualifies for the US tax credit

Any installation must be done according to the data and drawings detailed in the owner’s manual.

Specifications

General features

Alcove installation approved

Yes

Mobile home approved

Yes, with fresh air intake

Certified according to applicable standards

By an accredited laboratory (CAN/USA)

Overall dimension (Width)

28 1/8''

Overall dimension (Height)

36 3/8''

Overall dimension (Depth)

31 1/4''

Premium quality blower included (CFM)

Optional

Combustion technology

Non-catalytic

Stainless-steel secondary-air system

Yes

Flue outlet diameter

Distance-center of the flue outlet to back unit

Distance-center of the flue outlet to side unit

14 1/8"

Recommended chimney diameter

Type of chimney

CAN/ULC S629, UL 103 HT (2100 °F)

Minimum chimney height

12'

Door type

Single, glass with cast iron frame

Door opening size (Width)

19"

Door opening size (Height)

10 5/8"

Glass type

Ceramic glass

Glass surface - W x H

18 3/8" x 12 1/8"

Steel thickness-body

3/16"

Steel thickness-top

5/16"

Firebox size (Width)

22 7/8"

Firebox size (Height)

12 7/8"

Firebox size (Depth)

20 1/8"

Log positioning

Loading over width and over depth

Maximum log length

22"

Firebox lined with refractory bricks

Yes

Baffle type

High quality vermiculite

High-efficiency certified appliance

Yes, EPA 2020 approved

Canadian Standard (emissions)

CSA B415.1-10

USA Standard (emissions)

EPA

Canadian Standard (safety)

ULC S627

USA Standard (safety)

UL 1482, UL 737

Warranty

Limited lifetime

Shipping weight

525 lb (238 kg)

Approved as add-on to an existing furnace

Appliance performance

Fuel type

Dry cordwood (16" recommended)

Recommended heating area(9)

1,000 - 2,700 ft²

Overall firebox volume

3.5 ft³

EPA loading volume

2.88 ft³

Maximum burn time(9)

10 h

Maximum heat output-dry cordwood(4)

110,000 BTU/h (32.2 kW)

Minimum overall heat output rate(4)(5)

17,200 BTU/h (5.0 kW)

Maximum overall heat output rate(4)(5)

57,800 BTU/h (16.9 kW)

Average overall efficiency-dry cordwood (HHV)(5)(6)

71 %

Average overall efficiency-dry cordwood (LHV)(5)(7)

76 %

Optimum efficiency(1)(2)

77 %

Optimum heat transfer efficiency(8)

75 %

Average particulate emission rate(3)

1.6 g/h

Average CO(10)

73 g/h

Clearances

Canada

United States

Single wall pipe

Double wall pipe

Single wall pipe

Double wall pipe

Clearance - Back wall13 1/4"13 1/4"13 1/4"13 1/4"Clearance - Side wall14"14"14"14"Clearance - Corner7 1/4"7 1/4"7 1/4"7 1/4"Clearance - Base of the unit to ceiling**84"84"84"84"

Manuals and Instructions

Consult the available manuals and leaflets for more information on performance, installation and use requirements, etc.

Installation and user's manual

Appliance dimensions
