Century Heating
Century HeatingSKU: CB00022
CW2900
Out of stock
Free Curbside Delivery.See Shipping & Delivery PolicyLarge size firebox
Full description
INSERT CONFIGURATOR
Recommended for installation
These options allow you to get the most out of your appliance.
AC012985"Ø FRESH AIR INTAKE KIT
Out of stock
AC01315RIGID FIRESCREEN
Out of stock
AC01214OFFSET LINER ADAPTOR
Out of stock
Accessories
Description
- Large size firebox
- Spring faceplate adjustment system which easily adapts to any type of hearth
- Reinforced appliance top with a stainless steel heat shield
- Cast iron door and ceramic glass
- EPA certified at 2.3 g/h
- Non-catalytic combustion system
- Designed and made in Canada
- Included: 34" x 50" faceplate, air intake damper and 144 CFM blower with thermodisc
Specifications
General features
Alcove installation approved
No
Premium quality blower included (CFM)
144 CFM included
Certified according to applicable standards
CAN/USA accredited laboratory
Combustion technology
Non-catalytic
Stainless-steel secondary-air system
Yes
Flue outlet diameter
6"
Recommended chimney diameter
6"
Type of chimney
CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height
12"
Overall dimension (Width)
28 1/2"
Overall dimension (Height)
22 5/8"
Overall dimension (Depth)
26 1/2"
Door type
Single, glass with cast iron frame
Door opening size (Width)
17 1/2"
Door opening size (Height)
9"
Glass type
Ceramic glass
Glass surface - W x H
14 7/8" x 9 1/4"
Steel thickness-body
3/16"
Steel thickness-top
1/4"
Firebox size (Width)
21"
Firebox size (Height)
11 7/8"
Firebox size (Depth)
16 1/2"
Maximum log length
20" (16" recommended)
Log positioning
Loading over width
Firebox lined with refractory bricks
Yes
Baffle type
High quality vermiculite
Minimum fireplace opening (Width)
28 7/8"
Minimum fireplace opening (Height)
23 3/8"
Minimum fireplace opening (Depth)
15 3/4"
High-efficiency certified appliance
Yes, EPA 2020 approved
Canadian Standard (emissions)
CSA B415.1-10
USA Standard (emissions)
EPA
Canadian Standard (safety)
ULC S628
USA Standard (safety)
UL 1482, UL 737
Warranty
Limited 5 years
Shipping weight
415 lb (188 kg)
Appliance performance
Fuel type
Dry cordwood
Heating area(9)
1,700 - 2,900 ft²
Overall firebox volume
2.4 ft³s
EPA loading volume
1.95 ft³
Maximum burn time(9)
8 h
Maximum heat output-dry cordwood(4)
75,000 BTU/h
Minimum overall heat output rate(4)(5)
14,200 BTU/h (4.16 kW)
Maximum overall heat output rate(4)(5)
44,500 BTU/h (13.04 kW)
Average overall efficiency-dry cordwood (HHV)(5)(6)
72 %
Average overall efficiency-dry cordwood (LHV)(5)(7)
77 %
Optimum efficiency(1)(2)
79 %
Optimum heat transfer efficiency(8)
76 %
Average particulate emission rate(3)
2.3 g/h
Average CO(10)
69 g/h
Clearances
Canada
United States
