Ventis

VentisSKU: VB00024-Bundle

HEI90

Out of stock

Curbside Delivery.See Shipping & Delivery Policy

Tapered shape (top and sides) designed to fit the smallest masonry hearths

Full description

Dimension27 7/8"L X 20"P X 20 1/8"H

Heating area250 - 1,200 ft²

Maximum log length17" (16" recommended)

Average particulate emission rate1.5 g/h

Full specifications

INSERT CONFIGURATOR

Customize your productSubtotal: 0

Recommended for installation

Description

▪Small-sized wood insert suitable for tighter spaces
▪Tapered shape (top and sides) that simplifies installation in small masonry hearths
▪Glass airwash system for a cleaner view of the flames
▪EPA certified
▪Best-in-class performance with an efficiency rate of 75%
▪C-Cast heat shield added to the firestop
▪Non-catalytic combustion technology
▪Cast iron door
▪90 CFM blower with right/left powercord
▪Proudly made in Canada

Required option: regular faceplate (VBA1545)

Specifications

General features

Mobile home approved

Premium quality blower included (CFM)

90 CFM included

Certified according to applicable standards

CAN/USA accredited laboratory

Combustion technology

Non-catalytic

Stainless-steel secondary-air system

Yes

Flue outlet diameter

Distance-center of the flue outlet to back unit

5 1/8"

Distance-center of the flue outlet to side unit

10 5/8"

Recommended chimney diameter

Type of chimney

ULC-S635, CAN/ULC-S640, UL 1777

Minimum chimney height

12"

Overall dimension (Width)

27 7/8"

Overall dimension (Height)

20 1/8"

Overall dimension (Depth)

20"

Door type

Single, glass with cast iron frame

Door opening size (Width)

18 1/4"

Door opening size (Height)

7 7/8"

Glass type

Ceramic glass

Glass surface - W x H

17 7/8" x 8"

Steel thickness-body

3/16"

Steel thickness-top

3/16"

Firebox size (Width)

16 3/4"

Firebox size (Height)

8 7/8"

Firebox size (Depth)

12 3/8"

Maximum log length

17" (16" recommended)

Log positioning

Loading over width

Firebox lined with refractory bricks

Yes

Baffle type

C-Cast or equivalent

Minimum fireplace opening (Width)

25"

Minimum fireplace opening (Height)

19"

Minimum fireplace opening (Depth)

15 1/2"

High-efficiency certified appliance

Yes, EPA 2020 approved

Canadian Standard (emissions)

CSA B415.1-10

USA Standard (emissions)

EPA

Canadian Standard (safety)

ULC S628

USA Standard (safety)

UL 1482, UL 737

Warranty

Limited 5 years

Shipping weight

287 lb (130 kg)

Minimum fireplace opening (Height at the back)

17 1/4"

Minimum fireplace opening (Width at the back)

21 1/2"

Appliance performance

Fuel type

Dry cordwood

Heating area(9)

250 - 1,200 ft²

Overall firebox volume

1.1 ft³

EPA loading volume

1.03 ft³

Maximum burn time(9)

7 h

Maximum heat output-dry cordwood(4)

45,000 BTU/h

Minimum overall heat output rate(4)(5)

8,471 BTU/h (2.48 kW)

Maximum overall heat output rate(4)(5)

31,700 BTU/h (9.29 kW)

Average overall efficiency-dry cordwood (HHV)(5)(6)

75%

Average overall efficiency-dry cordwood (LHV)(5)(7)

80%

Optimum efficiency(1)(2)

82%

Optimum heat transfer efficiency(8)

78%

Average particulate emission rate(3)

1.5 g/h

Average CO(10)

34 g/h

Clearances

Canada

United States

Clearance - Combustible side wall to unit16"16"Clearance - Combustible side mantle to unit1"1"Clearance - Combustible top mantle to unit1"1"Clearance - Top of the unit to a 12" combustible mantle shelf34"34"Clearance - Base of the unit to ceiling**72"72"Clearance - Floor protection in front of the unit (from door opening)16"18"
