Ventis
VentisSKU: VB00015-Bundle
HE250R
Out of stock
Free Curbside Delivery.See Shipping & Delivery PolicyDesigned mainly for heating
Full description
Recommended for installation
Description
▪Designed mainly for heating
▪Large classic fireplace with single door
▪EPA 2020 certified
▪Non-catalytic combustion technology
▪Installation authorized on the Island of Montreal
▪Firestop made of high density insulation board
▪Ventis distinctive louvers included
▪176 CFM blower included
▪Molded refractory stones
▪6" Ventis stainless steel anchor plate included
▪Fresh air intake adapter included
Required: modern faceplate (VBA1560)
Specifications
General features
Baffle type
High density insulation board
Recommended chimney diameter
6"
Flue outlet diameter
6"
Firebox size (Height)
12 1/8"
Firebox size (Width)
20 3/8"
Firebox size (Depth)
13"
Overall dimension (Height)
37 1/4"
Overall dimension (Width)
36 3/4"
Overall dimension (Depth)
28 5/8"
Door opening size (Height)
10 9/16"
Door opening size (Width)
25 3/8"
High-efficiency certified appliance
Yes, EPA 2020 approved
Warranty
Lifetime limited
Minimum chimney height
15"
Maximum log length
20"
Canadian Standard (emissions)
CSA B415.1-10
USA Standard (emissions)
EPA
Canadian Standard (safety)
ULC S610
USA Standard (safety)
UL 127
Shipping weight
495 lb (225 kg)
Log positioning
Loading over width
Glass surface - W x H
24" x 10 5/8"
Stainless-steel secondary-air system
Yes
Combustion technology
Non-catalytic
Certified according to applicable standards
CAN/USA accredited laboratory
Type of chimney
CAN/ULC S629, UL 103 HT (2100 °F)
Door type
Single, glass with cast iron frame
Premium quality blower included (CFM)
176 CFM included
Glass type
Ceramic glass
Appliance performance
Optimum efficiency(1)(2)
70 %
Average particulate emission rate(3)
1.2 g/h
EPA loading volume
1.94 ft³
Maximum heat output-dry cordwood(4)
80,000 BTU/h
Maximum overall heat output rate(4)(5)
60,700 BTU/h (17.79 kW)
Minimum overall heat output rate(4)(5)
12,700 BTU/h (3.72 kW)
Average overall efficiency-dry cordwood (HHV)(5)(6)
64 %
Average overall efficiency-dry cordwood (LHV)(5)(7)
68 %
Optimum heat transfer efficiency(8)
68 %
Recommended heating area(9)
750 - 2,200 ft²
Average CO(10)
98 g/h
Maximum burn time(9)
8 h
Fuel type
Dry cordwood
(16" recommended)
Overall firebox volume
2.5 ft³
Clearances
Manuals and Instructions
Consult the available manuals and leaflets for more information on performance, installation and use requirements, etc.
