Drolet
DroletSKU: DB03182

ESCAPE 1200

Out of stock

Free Curbside Delivery.See Shipping & Delivery Policy

Our most compact unit in the series, the Escape 1200 is the perfect choice for heating homes up to 1,200 ft².

Full description
18 1/2"L X 28 7/8"P X 30 1/8"H
250 - 1,200 ft²
17"
1.8 g/h
Full specifications
Alain
ALAIN'S ADVICE
Description

Our most compact unit in the series, the Escape 1200 is the perfect choice for heating homes up to 1,200 ft². With only 1.8 g/h of particulate emissions, this EPA certified wood stove puts out an impressive 45,000 BTU/h. The bottom of its combustion chamber is deeper than other models in its category and allows a greater accumulation of ashes, and thus able to empty them less frequently. A simple model; reliable and robust.

Included: pedestal, air deflector, ceramic glass, cast iron door with adjustable hinges, ash lip, air damper, stainless steel heat shield

▪ Up to 5 hours burn time
▪ Up to 17" logs
▪ 1.55 ft³ firebox
▪ EPA certified
▪ Proudly made in Canada
▪ Limited lifetime warranty
▪ Certified for mobile home and alcove installation
▪ This model qualifies for the US tax credit
Any installation must be done according to the data and drawings detailed in the owner’s manual.

Specifications

General features

Alcove installation approved
Yes
Mobile home approved
Yes, with fresh air intake
Certified according to applicable standards
By an accredited laboratory (CAN/USA)
Overall dimension (Width)
18 1/2"
Overall dimension (Height)
30 1/8"
Overall dimension (Depth)
28 7/8"
Premium quality blower included (CFM)
Optional
Combustion technology
Non-catalytic
Stainless-steel secondary-air system
Yes
Flue outlet diameter
6"
Distance-center of the flue outlet to back unit
6 5/8"
Distance-center of the flue outlet to side unit
9 1/4"
Recommended chimney diameter
6"
Type of chimney
CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height
12'
Door type
Single, glass with cast iron frame
Door opening size (Width)
12"
Door opening size (Height)
7 5/8"
Glass type
Ceramic glass
Steel thickness-body
3/16"
Steel thickness-top
1/4"
Firebox size (Width)
14 1/4"
Firebox size (Height)
11 3/4"
Firebox size (Depth)
19 1/8"
Log positioning
Loading over depth
Maximum log length
17"
Firebox lined with refractory bricks
Yes
Baffle type
High quality vermiculite
High-efficiency certified appliance
Yes, EPA 2020 approved
Canadian Standard (emissions)
CSA B415.1-10
USA Standard (emissions)
EPA
Canadian Standard (safety)
ULC S627
USA Standard (safety)
UL 1482, UL 737
Warranty
Limited lifetime
Shipping weight
288 lb (130 kg)
Approved as add-on to an existing furnace
No

Appliance performance

Fuel type
Dry cordwood (16" recommended)
Heating area(9)
250 - 1,200 ft²
Overall firebox volume
1.8 ft³
EPA loading volume
1.55 ft³
Maximum burn time(9)
5 h
Maximum heat output-dry cordwood(4)
45,000 BTU/h (13.19 kW)
Minimum overall heat output rate(4)(5)
12,124 BTU/h (3.55 kW)
Maximum overall heat output rate(4)(5)
26,700 BTU/h (7.83 kW)
Average overall efficiency-dry cordwood (HHV)(5)(6)
74 %
Average overall efficiency-dry cordwood (LHV)(5)(7)
79 %
Optimum efficiency(1)(2)
80 %
Optimum heat transfer efficiency(8)
79 %
Average particulate emission rate(3)
1.8 g/h
Average CO(10)
74 g/h

Clearances

Canada
United States
Single wall pipe
Double wall pipe
Single wall pipe
Double wall pipe
Clearance - Back wall14"6"12"6"Clearance - Side wall18"18"18"18"Clearance - Corner11"7"11"7"Clearance - Base of the unit to ceiling**84"84"84"84"
Manuals and Instructions

Consult the available manuals and leaflets for more information on performance, installation and use requirements, etc.
