Englander
EnglanderSKU: ESW0001

BLUE RIDGE 100

Out of stock

Free Curbside Delivery.See Shipping & Delivery Policy

High efficiency 1.8 ft³ firebox, ideal for tight spaces.

Full description
18 1/2"L X 29"P X 30 5/8"H
250 - 1,200 ft²
17" (16" recommanded)
1.8 g/h
Full specifications
Alain
ALAIN'S ADVICE
Description

Our most compact unit in the series, the Blue Ridge 100 is the perfect choice for heating homes up to 1,200 ft². With only 1.8 g/h of particulate emissions, this EPA certified wood stove puts out an impressive 45,000 BTU/h. The bottom of its combustion chamber is deeper than other models in its category and allows a greater accumulation of ashes, and thus able to empty them less frequently. A simple model; reliable and robust.

Included: pedestal, ash lip, air intake damper & rear air deflector

▪ High efficiency 1.8 ft³ firebox, ideal for tight spaces
▪ Up to 5 hours burn time
▪ Steel top reinforced with a stainless steel heat shield
▪ High density refractory bricks
▪ Cast iron door and ceramic glass
▪ EPA certified
▪ Proudly made in USA
▪ Non-catalytic combustion system
▪ Certified for mobile home and alcove installation
▪ Qualifies for the 30% US tax credit

MANUFACTURER PROMOTION
Get a FREE heat activated blower (AC03513), value of $105, with the purchase of a Blue Ridge 100 (ESW0001) wood stove. Hurry, this offer is valid on purchases made from November 1st to 30th, 2024. For more details and claim your free item: >https://www.englander-stoves.com/us/en/promotions/

Specifications

General features

Alcove installation approved
Yes
Mobile home approved
Yes, with fresh air intake
Certified according to applicable standards
By an accredited laboratory (CAN/USA)
Overall dimension (Width)
18 1/2"
Overall dimension (Height)
30 5/8"
Overall dimension (Depth)
29"
Premium quality blower included (CFM)
Optional
Combustion technology
Non catalytic
Stainless-steel secondary-air system
Yes
Flue outlet diameter
6"
Distance-center of the flue outlet to back unit
6 5/8"
Distance-center of the flue outlet to side unit
9 1/4"
Recommended chimney diameter
6"
Type of chimney
CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height
12'
Door type
Single, glass with cast iron frame
Door opening size (Width)
12"
Door opening size (Height)
7 5/8"
Glass type
Ceramic glass
Glass surface - W x H
9 5/8" x 8 1/8"
Steel thickness-body
3/16"
Steel thickness-top
1/4"
Firebox size (Width)
14 1/4"
Firebox size (Height)
11 3/4"
Firebox size (Depth)
19 3/8"
Log positioning
Loading over depth
Maximum log length
17" (16" recommanded)
Firebox lined with refractory bricks
Yes
Baffle type
High quality vermiculite
High-efficiency certified appliance
Yes, EPA 2020 approved
Canadian Standard (emissions)
CSA B415.1-10
USA Standard (emissions)
EPA
Canadian Standard (safety)
ULC S627
USA Standard (safety)
1482, UL 737
Warranty
5 years limited
Shipping weight
283 lb (128 kg)

Appliance performance

Fuel type
Dry cordwood (16" recommended)
Heating area(9)
250 - 1,200 ft²
Overall firebox volume
1.8 ft³
EPA loading volume
1.55 ft³
Maximum burn time(9)
5 h
Maximum heat output-dry cordwood(4)
45,000 BTU/h (13.2 kW)
Minimum overall heat output rate(4)(5)
12,124 BTU/h (3.55 kW)
Maximum overall heat output rate(4)(5)
26,700 BTU/h (7.83 kW)
Average overall efficiency-dry cordwood (HHV)(5)(6)
74 %
Average overall efficiency-dry cordwood (LHV)(5)(7)
79 %
Optimum efficiency(1)(2)
80 %
Optimum heat transfer efficiency(8)
79 %
Average particulate emission rate(3)
1.8 g/h
Average CO(10)
74 g/h

Clearances

Canada
United States
Single wall pipe
Double wall pipe
Single wall pipe
Double wall pipe
Clearance - Back wall14"6"12"6"Clearance - Side wall18"18"18"18"Clearance - Corner11"7"11"7"Clearance - Base of the unit to ceiling**84"84"84"84"
