Osburn
OsburnSKU: OB00950

Osburn 950

Out of stock

Free Curbside Delivery.See Shipping & Delivery Policy

Would you like to add a dose of warmth and cozyness to your home? Bring comfort and functionality to your daily life with the Osburn 950, a small wood stove that will quickly become your cold-season essential. Equipped with high density bricks, a stainless steel heat shield added to the C-Cast firestop, a top heat deflector to redirect heat in front of the stove as well as side panels that reduce clearances, the Osburn 950 offers quality and performance. Enjoy your winter evenings more than ever before! *Any installation must be done according to the data and drawings detailed in the owner’s manual.*

Full description
20 1/4"L X 27 7/8"P X 28 7/8"H
250 - 1,200 ft²
17"
1.8 g/h
Full specifications
Description

Would you like to add a dose of warmth and cozyness to your home? Bring comfort and functionality to your daily life with the Osburn 950, a small wood stove that will quickly become your cold-season essential.

Equipped with high density bricks, a stainless steel heat shield added to the C-Cast firestop, a top heat deflector to redirect heat in front of the stove as well as side panels that reduce clearances, the Osburn 950 offers quality and performance. Enjoy your winter evenings more than ever before!

Any installation must be done according to the data and drawings detailed in the owner’s manual.

Specifications

General features

Alcove installation approved
Yes
Mobile home approved
Yes, with fresh air intake
Certified according to applicable standards
By an accredited laboratory (CAN/USA)
Overall dimension (Width)
20 1/4"
Overall dimension (Height)
28 7/8"
Overall dimension (Depth)
27 7/8"
Premium quality blower included (CFM)
Optional
Combustion technology
Non-catalytic
Stainless-steel secondary-air system
Yes
Flue outlet diameter
6"
Distance-center of the flue outlet to back unit
6 5/8"
Distance-center of the flue outlet to side unit
10 1/8"
Recommended chimney diameter
6"
Type of chimney
CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height
12'
Door type
Single, glass with cast iron frame
Door opening size (Width)
12"
Door opening size (Height)
7 5/8"
Glass type
Ceramic glass
Glass surface - W x H
10 1/4" x 8 7/8"
Steel thickness-body
3/16"
Steel thickness-top
5/16"
Firebox size (Width)
14 1/4"
Firebox size (Height)
11 3/4"
Firebox size (Depth)
19 1/8"
Log positioning
Loading over depth
Maximum log length
17"
Firebox lined with refractory bricks
Yes
Baffle type
C-Cast or equivalent
High-efficiency certified appliance
Yes, EPA 2020 approved
Canadian Standard (emissions)
CSA B415.1-10
USA Standard (emissions)
EPA
Canadian Standard (safety)
ULC S627
USA Standard (safety)
UL 1482, UL 737
Warranty
Limited lifetime
Shipping weight
324 lb (147 kg)

Appliance performance

Fuel type
Dry cordwood (16" recommended)
Recommended heating area(9)
250 - 1,200 ft²
Overall firebox volume
1.8 ft³
EPA loading volume
1.55 ft³
Maximum burn time(9)
5 h
Maximum heat output-dry cordwood(4)
45,000 BTU/h (13.19 kW)
Minimum overall heat output rate(4)(5)
12,124 BTU/h (3.55 kW)
Maximum overall heat output rate(4)(5)
26,700 BTU/h (7.83 kW)
Average overall efficiency-dry cordwood (HHV)(5)(6)
74 %
Average overall efficiency-dry cordwood (LHV)(5)(7)
79 %
Optimum efficiency(1)(2)
80 %
Optimum heat transfer efficiency(8)
79 %
Average particulate emission rate(3)
1.8 g/h
Average CO(10)
74 g/h

Clearances

Canada
United States
Single wall pipe
Double wall pipe
Single wall pipe
Double wall pipe
Clearance - Back wall14"6"12"6"Clearance - Side wall12"12"12"12"Clearance - Corner11"6"11"6"Clearance - Base of the unit to ceiling**84"84"84"84"
Manuals and Instructions

Consult the available manuals and leaflets for more information on performance, installation and use requirements, etc.
