Century Heating
Century HeatingSKU: CB00030
CW2800
Out of stock
Free Curbside Delivery.See Shipping & Delivery PolicyMedium size firebox
Full description
INSERT CONFIGURATOR
Recommended for installation
These options allow you to get the most out of your appliance.
AC01299RIGID FIRESCREEN
Out of stock
AC012985"Ø FRESH AIR INTAKE KIT
Out of stock
AC01214OFFSET LINER ADAPTOR
Out of stock
Accessories
Description
- Mid-size, versatile firebox
- Reinforced appliance top with a stainless steel heat shield
- Cast iron door and ceramic glass
- EPA certified at 2.4 g/h
- Non-catalytic combustion system
- Designed and made in Canada
- Included: 32" x 44" faceplate, air intake damper and 144 CFM blower with thermodisc
Specifications
General features
Alcove installation approved
No
Premium quality blower included (CFM)
144 CFM included
Certified according to applicable standards
CAN/USA accredited laboratory
Combustion technology
Non-catalytic
Stainless-steel secondary-air system
Yes
Flue outlet diameter
6"
Distance-center of the flue outlet to back unit
5 3/4"
Distance-center of the flue outlet to side unit
12 3/4"
Recommended chimney diameter
6"
Type of chimney
ULC-S635, CAN/ULC-S640, UL 1777
Minimum chimney height
12"
Overall dimension (Width)
27 1/4"
Overall dimension (Height)
21 1/4"
Overall dimension (Depth)
22 1/4"
Door type
Single, glass with cast iron frame
Door opening size (Width)
17 1/4"
Door opening size (Height)
8"
Glass type
Ceramic glass
Glass surface - W x H
14 7/8" x 9 1/4"
Steel thickness-body
3/16"
Steel thickness-top
1/4"
Firebox size (Width)
19 5/8"
Firebox size (Height)
11 7/8"
Firebox size (Depth)
13 1/2"
Maximum log length
18" (16" recommended)
Log positioning
Loading over width
Firebox lined with refractory bricks
Yes
Baffle type
High quality vermiculite
Minimum fireplace opening (Width)
27 1/2"
Minimum fireplace opening (Height)
21 1/2"
Minimum fireplace opening (Depth)
12 3/4"
High-efficiency certified appliance
Yes, EPA 2020 approved
Canadian Standard (emissions)
CSA B415.1-10
USA Standard (emissions)
EPA
Canadian Standard (safety)
ULC S628
USA Standard (safety)
UL 1482, UL 737
Warranty
Limited 5 years
Shipping weight
360 lb (163 kg)
Appliance performance
Fuel type
Dry cordwood
Heating area(9)
1,500 - 2,400 ft²
Overall firebox volume
1.86 ft³
EPA loading volume
1.44 ft³
Maximum burn time(9)
7 h
Maximum heat output-dry cordwood(4)
65,000 BTU/h (19 kW)
Minimum overall heat output rate(4)(5)
9,800 BTU/h (2.87 kW)
Maximum overall heat output rate(4)(5)
52,200 BTU/h (15.3 kW)
Average overall efficiency-dry cordwood (HHV)(5)(6)
68 %
Average overall efficiency-dry cordwood (LHV)(5)(7)
73 %
Optimum efficiency(1)(2)
76 %
Optimum heat transfer efficiency(8)
75 %
Average particulate emission rate(3)
2.4 g/h
Average CO(10)
103 g/h
Clearances
Canada
United States
Manuals and Instructions
Consult the available manuals and leaflets for more information on performance, installation and use requirements, etc.
