Heaters
/
Wood Inserts
/DB03137
Drolet
DroletSKU: DB03137

ESCAPE 1500-I - WITH FACEPLATE

Out of stock

Free Curbside Delivery.See Shipping & Delivery Policy

Combining performance and respect for the environment, the Escape 1500 is the perfect choice for heating homes up to 1,800 ft²

Full description
27 1/4"L X 22 3/8"P X 21 1/4"H
500 - 1,800 ft²
18"
2.4 g/h
Full specifications
INSERT CONFIGURATOR

Recommended for installation

These options allow you to get the most out of your appliance.

Out of stock

Out of stock

Out of stock

Subtotal:USD $0.00

Accessories

DELIVERY AVAILABLE IN CANADA AND USA*.BEST DEALS OF THE MONTH ON OUR PRODUCTSEXPERT TEAM READY TO HELP
Description

Combining performance and respect for the environment, the Escape 1500 is the perfect choice for heating homes up to 1,800 ft². With only 2.4 g/h of particulate emissions, this non-catalytic wood insert gives off up to 65,000 BTU/h while largely meeting EPA standards. The Escape 1500 is the perfect way to update your masonry fireplace, and make it efficient!

Included: 29" x 44" faceplate, blower, ceramic glass, ash lip, air damper

▪Burn time up to 7 hours
▪Up to 18" logs
▪Robust 5/16" steel reinforced with a stainless steel heat shield
▪EPA certified
▪Proudly made in Canada
▪Limited lifetime warranty

Any installation must be done according to the data and drawings detailed in the owner’s manual.

Specifications

General features

Premium quality blower included (CFM)
144 CFM included
Certified according to applicable standards
By an accredited laboratory (CAN/USA)
Combustion technology
Non-catalytic
Stainless-steel secondary-air system
Yes
Flue outlet diameter
6"
Distance-center of the flue outlet to back unit
5 3/4"
Distance-center of the flue outlet to side unit
12 3/4"
Recommended chimney diameter
6"
Type of chimney
Liner - ULC-S635, CAN/ULC-S640, UL1777
Minimum chimney height
12'
Overall dimension (Width)
27 1/4"
Overall dimension (Height)
21 1/4"
Overall dimension (Depth)
22 3/8"
Door type
Single, glass with cast iron frame
Door opening size (Width)
17 1/4"
Door opening size (Height)
8 3/4"
Glass type
Ceramic glass
Glass surface - W x H
15 3/4" x 9 3/4"
Steel thickness-body
3/16"
Steel thickness-top
5/16"
Firebox size (Width)
19 5/8"
Firebox size (Height)
11 7/8"
Firebox size (Depth)
13 1/2"
Maximum log length
18"
Log positioning
Loading over width
Firebox lined with refractory bricks
Yes
Baffle type
High quality vermiculite
Minimum fireplace opening (Width)
27 1/2"
Minimum fireplace opening (Height)
21 1/2"
Minimum fireplace opening (Depth)
12 3/4"
High-efficiency certified appliance
Yes, EPA 2020 approved
Canadian Standard (emissions)
CSA B415.1-10
USA Standard (emissions)
EPA
Canadian Standard (safety)
ULC S628
USA Standard (safety)
UL 1482, UL 737
Warranty
Limited lifetime
Shipping weight
360 lb (163 kg)
Approved as add-on to an existing furnace
No

Appliance performance

Fuel type
Dry cordwood (16" recommended)
Heating area(9)
500 - 1,800 ft²
Overall firebox volume
1.86 ft³
EPA loading volume
1.44 ft³
Maximum burn time(9)
7 h
Maximum heat output-dry cordwood(4)
65,000 BTU/h (19 kW)
Minimum overall heat output rate(4)(5)
9,800 BTU/h (2.87 kW)
Maximum overall heat output rate(4)(5)
52,200 BTU/h (15.3 kW)
Average overall efficiency-dry cordwood (HHV)(5)(6)
68 %
Average overall efficiency-dry cordwood (LHV)(5)(7)
73 %
Optimum efficiency(1)(2)
76 %
Optimum heat transfer efficiency(8)
75 %
Average particulate emission rate(3)
2.4 g/h
Average CO(10)
103 g/h

Clearances

Canada
United States
Clearance - Combustible side wall to unit16"16"Clearance - Combustible side mantle to unit9"9"Clearance - Combustible top mantle to unit27"27"Clearance - Top of the unit to a 12" combustible mantle shelf27"27"Clearance - Base of the unit to ceiling**84"84"
Manuals and Instructions

Consult the available manuals and leaflets for more information on performance, installation and use requirements, etc.

Wood insert manual | Safety notifications & general information
Appliance dimensions
Installation & Operation Requirements
