EnerzoneSKU: EB00064-Bundle

SOLUTION 2.3-I

Out of stock

Free Curbside Delivery.See Shipping & Delivery Policy

Designed to be a powerful unit, the Solution 2.3 insert offers a surprising quality of combustion.

Full description

Dimension28 5/8"L X 27"P X 22 7/8"H

Recommended heating area500 - 2,100 ft²

Maximum log length20"

Average particulate emission rate2.3 g/h

Full specifications

INSERT CONFIGURATOR

Customize your productSubtotal: 0

Recommended for installation

Accessories

Description

Designed to be a powerful unit, the Solution 2.3 insert offers a surprising quality of combustion. Every detail is thoughtfully planned to optimize its performance, which far exceeds the latest industry standards.

Many of its features are identical to its freestanding counterpart. Strategically positioned, a powerful heat-activated fan (144 CFM) allows an optimal redistribution of the heat produced by the firebox in the room. In addition, its design allows it to receive a faceplate whose dimensions can cover a masonry hearth with a maximum height of 32 inches and width of 50 inches. Designed for those looking for an eco-friendly and efficient stove; the best of both worlds!

Specifications

General features

Mobile home approved

Premium quality blower included (CFM)

144 CFM included

Certified according to applicable standards

By an accredited laboratory (CAN/USA)

Combustion technology

Non-catalytic

Stainless-steel secondary-air system

Yes

Flue outlet diameter

Distance-center of the flue outlet to back unit

6 3/4"

Distance-center of the flue outlet to side unit

13 1/2"

Recommended chimney diameter

Type of chimney

Liner - ULC-S635, CAN/ULC-S640, UL1777

Minimum chimney height

12'

Overall dimension (Width)

28 5/8"

Overall dimension (Height)

22 7/8"

Overall dimension (Depth)

27"

Door type

Single, glass with cast iron frame

Door opening size (Width)

17 1/2"

Door opening size (Height)

Glass type

Ceramic glass

Glass surface - W x H

16 5/8" x 10 5/8"

Steel thickness-body

3/16"

Steel thickness-top

3/8"

Firebox size (Width)

21"

Firebox size (Height)

11 7/8"

Firebox size (Depth)

16 1/2"

Maximum log length

20"

Log positioning

Loading over width

Firebox lined with refractory bricks

Yes

Baffle type

C-Cast or equivalent

Minimum fireplace opening (Width)

28 7/8"

Minimum fireplace opening (Height)

23 3/8"

Minimum fireplace opening (Depth)

15 3/4"

High-efficiency certified appliance

Yes, EPA 2020 approved

Canadian Standard (emissions)

CSA B415.1-10

USA Standard (emissions)

EPA

Canadian Standard (safety)

ULC S628

USA Standard (safety)

UL 1482, UL 737

Warranty

Limited lifetime

Shipping weight

456 lb (207 kg)

Appliance performance

Fuel type

Dry cordwood (16" recommended)

Recommended heating area(9)

500 - 2,100 ft²

Overall firebox volume

2.4 ft³

EPA loading volume

1.95 ft³

Maximum burn time(9)

8 h

Maximum heat output-dry cordwood(4)

75,000 BTU/h (22.0 kW)

Minimum overall heat output rate(4)(5)

14,200 BTU/h (4.16 kW)

Maximum overall heat output rate(4)(5)

44,500 BTU/h (13.04 kW)

Average overall efficiency-dry cordwood (HHV)(5)(6)

72 %

Average overall efficiency-dry cordwood (LHV)(5)(7)

77 %

Optimum efficiency(1)(2)

79 %

Optimum heat transfer efficiency(8)

76 %

Average particulate emission rate(3)

2.3 g/h

Average CO(10)

69 g/h

Clearances

Canada

United States

Clearance - Combustible side wall to unit16"16"Clearance - Combustible side mantle to unit9"9"Clearance - Combustible top mantle to unit27"27"Clearance - Top of the unit to a 12" combustible mantle shelf27"27"Clearance - Base of the unit to ceiling**84" 84"

Manuals and Instructions

Consult the available manuals and leaflets for more information on performance, installation and use requirements, etc.

Wood insert manual | Safety notifications & general information

Appliance dimensions

Installation & Operation Requirements
