EnerzoneSKU: EB00066

DESTINATION 1.9

Out of stock

Free Curbside Delivery.See Shipping & Delivery Policy

Designed for the smallest masonry hearths thanks to its tapered shape, the Destination 1.9 is a compact and easy to install wood insert.

Full description
36"L X 21"P X 23 7/8"H
250 - 1,200 ft²
17"
1.5 g/h
Full specifications
INSERT CONFIGURATOR
Description

Designed for the smallest masonry hearths thanks to its tapered shape, the Destination 1.9 is a compact and easy to install wood insert. Its non-catalytic combustion and its 75% efficiency rate (the highest in its category) make it the perfect choice for those who want to transform their open fireplace into a clean and efficient heat source. To facilitate use and maintenance, its firebox has a hollow bottom for the accumulation of ashes, which helps reduce the frequency of cleaning.

Enjoy a panoramic view of the fire thanks to its large ceramic glass and arched cast iron door, fitted with a discreet black wood handle. The flush mount blower and the removable handle air control concealed in the faceplate louver give the Destination 1.9 a modern, clean finish that showcases the beauty of the flames.

Specifications

General features

Mobile home approved
No
Premium quality blower included (CFM)
90 CFM included
Certified according to applicable standards
By an accredited laboratory (CAN/USA)
Combustion technology
Non-catalytic
Stainless-steel secondary-air system
Yes
Flue outlet diameter
6"
Distance-center of the flue outlet to back unit
5 1/8"
Distance-center of the flue outlet to side unit
10 5/8"
Recommended chimney diameter
6"
Type of chimney
Liner - ULC-S635, CAN/ULC-S640, UL1777
Minimum chimney height
12'
Overall dimension (Width)
36"
Overall dimension (Height)
23 7/8"
Overall dimension (Depth)
21"
Door type
Single, glass with cast iron frame
Door opening size (Width)
18 1/4"
Door opening size (Height)
7 7/8"
Glass type
Ceramic glass
Glass surface - W x H
18" x 8 1/8"
Steel thickness-body
3/16"
Steel thickness-top
3/16"
Firebox size (Width)
16 3/4"
Firebox size (Height)
8 7/8"
Firebox size (Depth)
12 3/8"
Maximum log length
17"
Log positioning
Loading over width
Moulded refractory panels
Yes
Baffle type
C-Cast or equivalent
Minimum fireplace opening (Width)
25"
Minimum fireplace opening (Height)
19"
Minimum fireplace opening (Depth)
15 1/2"
High-efficiency certified appliance
Yes, EPA 2020 approved
Canadian Standard (emissions)
CSA B415.1-10
USA Standard (emissions)
EPA
Canadian Standard (safety)
ULC S628
USA Standard (safety)
UL 1482, UL 737
Warranty
Limited lifetime
Shipping weight
336 lb (152 kg)
Minimum fireplace opening (Height at the back)
17 1/4"
Minimum fireplace opening (Width at the back)
21 1/2"

Appliance performance

Fuel type
Dry cordwood (16" recommended)
Heating area(9)
250 - 1,200 ft²
Overall firebox volume
1.1 ft³
EPA loading volume
1.03 ft³
Maximum burn time(9)
7 h
Maximum heat output-dry cordwood(4)
45,000 BTU/h (13.16 kW)
Minimum overall heat output rate(4)(5)
8,471 BTU/h (2.48 kW)
Maximum overall heat output rate(4)(5)
31,700 BTU/h (9.29 kW)
Average overall efficiency-dry cordwood (HHV)(5)(6)
75 %
Average overall efficiency-dry cordwood (LHV)(5)(7)
80 %
Optimum efficiency(1)(2)
82 %
Optimum heat transfer efficiency(8)
78 %
Average particulate emission rate(3)
1.5 g/h
Average CO(10)
34 g/h

Clearances

Canada
United States
Clearance - Combustible side wall to unit16"16"Clearance - Combustible side mantle to unit1"1"Clearance - Combustible top mantle to unit1"1"Clearance - Base of the unit to a combustible shelf34"34"Clearance - Base of the unit to ceiling**72"72"
Manuals and Instructions

Consult the available manuals and leaflets for more information on performance, installation and use requirements, etc.
